Fig.1

1.Unscrewandremovethebloweraccess

panel.SeeFig.1.

Beforeinstallingtheblower,becertain

toturnofftheunit,andallowtimefor

unittocooldown.

Fig.2

2.Attachblower(B)ontothebloweraccess

panelwithM4.2X8screws(AA).SeeFig.2.

Hardware Used

M4.2X8screws

x4

Instruction for the models CRHQD250T (Item # 0293811), CRHSD25RT (Item # 0328253),

CRHFD400RT-M-M (Item # 0328248), BD23 series, Q stove, PCSD25RT series and FBD400

series.
